Construction of Tubular Steel Fuselages Overview:

Construction of Tubular Steel Fuselages Book

Construction of Tubular Steel Fuselages is written to assist mechanics and aircraft builders in producing a tubular steel airframe comparable to factory standards. The manual outlines assembly methods designed to achieve a highly accurate fuselage while allowing expansion and contraction to occur symmetrically without distortion.

Practical techniques are covered in detail, including jigging and alignment methods that support rapid prototyping without the need for elaborate welding jigs. This makes it a valuable resource for builders seeking precision and efficiency in aircraft construction.

The book walks through the complete fuselage design and construction process in a clear, practical manner. It is geared toward builders and technicians, not engineers, and includes guidance on loads, fittings, joints, welding, metalworking techniques, tool usage, and step-by-step construction of top and bottom fuselage sections. It also addresses sub-assemblies common to a wide range of tubular aircraft, from J3 replicas to high-performance aerobatic aircraft.

Product Details:

• Softcover
• 158 pages

Table of Contents:

• Welded Fuselage Construction and Design
• terminology
• axes
• fuselage geometry
• drawing conventions
• weld design
• materials
• designing parts
• Methods & Processes
• steel
• abrasives
• welding
• nonstructural attach points
• corrosion and removal
• cleaning and painting
• metrology for jigging
• Tools
• Jig Tables
• flat and level
• materials
• order of construction
• Layout
• centerlines
• drawing tops and bottoms
• Constructing the Top and Bottom
• blocks
• shims
• longerons
• constructing the top
• constructing the bottom
• Fitting the Top and Bottom
• hangers
• setting the bottom
• firewall reference plates
• setting the top
• upright crossmembers
• longerons on the firewall
• Welding the Fuselage
• welding the joints
• longeron straightening caused by welding
• starting welding
• fabricating engine mount pads
• finishing welding
• rudder post
• Horizontal Vertical Stabilizer and Control Surfaces
• Seats, Rollover Structures, Harness Installations
• Appendix
• attach points and connections
• reference materials and suppliers
• geometry
• recommendations for 4130 steel
